Reotemp M52 5-VALVE MANIFOLD VALVE

M52 5-VALVE MANIFOLD
Manifolds are essential for protecting differential pressure instruments and for easily removing an instrument from service for maintenance, testing, and replacement.

Complies with MSS SP-99 and MSS SP-132
Rolled Threads for Strength, Durability, and Ease of Use
316SS Body Option Complies with NACE MR0175
Vent Plug Standard Except for Inlet Facing Vents
Leak Tested Before Shipping
Can be Pre-installed on Many Reotemp and Customer Supplied InstrumentsBody Material: 316 Stainless Steel, Carbon Steel, Monel, Hastelloy C276, Duplex 2205, Super Duplex 2507
Max Pressure Rating Available: 10,000 psi
Min/Max Temperature Ratings: -67°F to 1,000°F
Seats Available: Hard, POM, PEEK, PCTFE, ETFE
Connections Available: 1/4″ NPT, 1/2″ NPT, Flanged, DIN EN 61518-A, DIN EN 61518-B, Grooveless Flanged, Coplanar
