Reotemp G22 VALVE BLOCK

G22 2-VALVE BLOCK & BLEED
Block and bleed valves allow pressure isolation, venting, and instrument removal without shutting down the system. The 1/4” NPT port allows easy calibration checks, venting to atmosphere, or capturing process media with direct connection to piping.

Complies with MSS SP-99 and MSS SP-132 Standards Where Applicable
Rolled Threads for Strength, Durability, and Ease of Use
Bleed Plug Standard
316SS Body Option Complies with NACE MR0175
Leak Tested Before Shipping
Available Factory-Installed on Reotemp InstrumentsBody Material: 316SS, Carbon Steel, Monel, Hastelloy C276, Duplex 2205, Super Duplex 2507
Max Pressure Rating: 10,000 psi
Min/Max Temperature Rating: -67°F to 1,000°F
Seats Available: Hard, POM, PEEK, PCTFE
Connections Available: 1/4”NPT, 1/2”NPT, 3/4″MNPT
Bleed Connection: 1/4”FNPT
