Seametrics iMAG 4700 Magmeter Magmeter

Seametrics iMAG 4700 Magmeter
Part:
iMAG 4700
The iMAG-Series is the most economical flanged electromagnetic flowmeter on the market.
Minimal straight pipe
Mounted or remote display
Tamper-evident seal
Certified to NSF/ANSI standard 61 • IP68 rated
Battery or external DC power versions
Pulse output standardiMAG 4700 Series Flanged Magmeter
With electrodes designed to discourage fouling, it is available in 2 inch to 12 inch pipe in municipal or industrial water, waste and reclaimed water, pump stations, and packaged plant applications. Minimal straight pipe requirements allow iMAG-Series meters to be used in piping configurations where there is little space between the meter and an elbow.

Bidirectional flow reading is standard with totals available in forward, reverse, net flow, batch forward flow, and batch reverse flow. Built-in data logging is available as an option for secure flow logging.

iMAG-Series meters are CE certified, certified to NSF/ANSI standard 61 and are rated IP68 for applications where the meter may be operated under water to a depth of at least 10 feet (3 meters) continuously.

The iMAG 4700 is also available in either AC or DC powered versions, with battery backup.

Applications
Water & Wastewater Treatment
Municipal
Pump skids
Pump stations
Packaged plants
Filtration systems
Reclaimed water
Hydraulic fracturing
