Models 520 | 530 –
Analytically Correct Engineered Systems™ are tailored to the specific application and designed to ensure sample integrity is maintained throughout the sample extraction and preconditioning process. The Lean Gas Sample System is an ACES™ tailored to the Natural Gas Industry. Consisting of a heated and insulated enclosure mounted on a membrane tipped Genie® Probe Regulator™. It is best suited to sampling natural gas at conditions above the hydrocarbon dew point temperature or near the hydrocarbon dew point at pressures below the cricondentherm. A typical application is the sampling of transmission quality natural gas sampling at locations where ambient temperatures could cause condensation.

Genie® Membrane Technology™ on the tip of the Probe Regulator™ separates liquid at source conditions to ensure a representative gas sample and to protect the analyzer by excluding contaminants from the entire sample handling system. Genie® Membrane Probes™ are designed to be safely retracted from a pressurized source without any special tools, so the Genie® membrane can be easily accessed and maintained. The GP series utilizes a housing with a foot valve for process isolation. The Genie® Direct Drive™ series is inserted and retracted through a full port process isolation valve. The regulator seat in a Probe Regulator™ is near the probe tip to prevent condensation by using the gas stream flowing past the probe as a heat source to help compensate for the Joule- Thomson (JT) cooling effect and prevent condensation.

Rounding off our ACES™ systems is a removable probe mounted enclosure that is insulated and heated to prevent ambient temperature from adversely impacting the sample. The Lean Gas Sample System produces a low-pressure, liquid-free sample, that is representative of the source and ready for transport to the analyzer.
