Electronics & Innovation, Ltd. AL20W-HF Amplifier

E&I provides reliable RF amplifier modules that cover frequencies from 10kHz - 200MHz, with power levels ranging from 5W - 200W. The same technology used in our benchtop solutions is now offered in modules, pallets, and subsystems.



The same E&I quality, now in modular form.



Narrowband and broadband solutions from 10kHz - 200MHz

Smaller physical footprint than benchtop amplifiers

10M200 0.3 MHz 200 MHz 10 W 24 VDC 40 dB ± 1.5 dB < -20 dBc

FORTE-50 0.25 MHz 50 MHz 50 W 28 VDC 48 dB ± 2 dB < -25 dBc

M-2100-T 0.01 MHz 12 MHz 100 W 42 and 24 VDC 50 dB ± 1.5 dB < -25 dBc

AL10W-HF 5 MHz 25 MHz 10 W 12.5 VDC 48 dB ± 2 dB < -10 dBc

M-1020-T 0.01 MHz 5 MHz 200 W 42 and 24 VDC 53 dB ± 1.5 dB < -15 dBc

M-0240-T 0.01 MHz 12 MHz 40 W 42 and 24 VDC 50 dB ± 1.5 dB < -25 dBc

M-A075-T 0.3 MHz 35 MHz 75 W 42 and 24 VDC 50 dB ± 1.5 dB < -25 dBc

AL10W-LF 0.5 MHz 20 MHz 10 W 12.5 VDC 47 dB ± 1 dB < -10 dBc

15M30 2 MHz 30 MHz 15 W 24 VDC 42 dB ± 1.5 dB < -25 dBc

CDA-LF-HP 0.01 MHz 20 MHz 5 W 24 VDC 40 dB ± 1.5 dB < -25 dBc

AL20W-HF 20 MHz 200 MHz 20 W 24 VDC 48 dB ± 2 dB < -15 dBc

AL20W-LF 0.25 MHz 50 MHz 20 W 24 VDC 52 dB ± 2 dB < -15 dBc
