tinlee MT- 50/75 - 50 Matching Transformers
Description
MT-50/75 is designed to impedance match a 75
ohm device to 50 ohms device. It is used to mini
mize mismatch and signal reflection. Example appli
cations: test and measurement - test 75 ohms de
vice using 50 ohms RF analyzer with a pair of MT
50/75s; Impedance match 50 ohms antenna to 75
ohms receiver using one MT in line.MT-50/75 is a
cost-efficient solution to convert a 75 ohm signal for
a 50 ohm measurement or transformation purposes,
or vice versa. It does this with good return loss to
improve measurement accuracy. A further advan
tage of this matching transformer is that it features a
low through loss, preserving much more of your in
put signal than a matching pad (6 dB) would.
Optional MT 50/75 models for 5 to 1500 MHz and
10 to 2000 MHz are available for some connector
configurations.Frequency Range (MHz) 5-15 20 to 870 900-1000
Insertion Loss (dB): 0.25 0.5 0.65
Return Loss (dB) - 50 ohms: >18 (VSWR 1.28) >20 (VSWR 1.21) >20 (VSWR 1.21)
Return Loss (dB) - 75 ohms: >18 (VSWR 1.28) >20(VSWR 1.21) >20 (VSWR 1.21)
RF Power Handling:
Dimensions (in): 2.75L x 0.75D x 1.0H (with connectors) Weight (lbs): 0.15
Connectors - 50 ohm port: BNC, SMA, or N type, female (inquire for availability for male end)
Connectors - 75 ohm port: F-female - standard , F-male and BNC female available
MT-50-75 (1000 to 1500 MHz) * 19 dB R.L. (VSWR 1.25); Insertion Loss: .75 dB from 1000 to 1500 MHz
MT-50/75 (1500 to 2000 MHz) * 18 dB R.L. (VSWR 1.28); Insertion Loss: 1.0 dB from 1000 to 2000 MHz
Up to 2 Watt (special order for 10 Watt )
Specifications: MT-50/75
MT 50/75 Compact, Rugged, RF shielded casing
Example Models Connectors*
MT-50/75 BfFf 50 Ω BNC female and 75 Ω F female
MT-50/75 BfFm 50 Ω BNC female and 75Ω F male
MT-50/75 SfBf 50 Ω SMA female and 75 Ω BNC female
MT-50/75 NmBf 50 Ω N male and 75 Ω BNC female
MT-50/75 NfBf 1.5G 50 Ω N (f), 75 Ω BNC female with 1500 MHz BW
MT-50/75 SfFm2.0G 50 Ω SMA(f), 75 Ω F female with 2000 MHz BW
