LSOC/LSOP
Single-Axis Analog Inclinometer
The Jewell LSOC/LSOP Series 昀氀uid damped,
昀
氀exure suspesion, servo inclinometer is a precision
internal grade sensing instruments and it is
Jewell’s most robust solution designed to meet
the needs of a variety of commercial, industrial,
and aerospace applications. LSOC/LSOP Series is
a 昀氀uid damped design. Units are available with a
6-pin connector, or pin-terminals and in ±5V and
4-20mA outputs.
FEATURES:
• Extremely high resolution and low hysteresis of
less than 0.0005% of full range output.
• Extremely robust designed to withstand shocks
in excess of 1500g and vibration of 20 grms.
• Responds to changes of slope as small as
0.000006”/ft.
• High accuracy closed-loop force balanced
sensor technology.
• RoHS compliant
• Low white noise spectral density of better than
0.15µV/Sq. Root HAPPLICATIONS:
• Steel Processing
• Continuous Casting
• Electric Arc Furnace
• Idle Control
• Heavy construction
• Paving
• Grading
• Mining
• Tunneling
• Overturn Detection
• Structural Monitoring
• Automated Train Controls
• Rail Leveling and Grinding
• Rail Bed Analysis
