Blocking Matrix Switches
A blocking matrix switch is constructed with RF switches on both halves of the matrix.  Each input signal can be switched to only one output port at a time.  If your application requires an input to be available to more than one output simultaneously, then a non-blocking matrix becomes necessary.

The two most notable advantages of a blocking matrix switch are insertion loss and isolation.  Because the matrix construction uses only RF switches, the insertion loss will be lower than any other matrix configuration.  Using only RF switches also makes it possible to maintain very high isolation from input to output because RF switches have better isolation characteristics than power divider/combiners.  The one disadvantage is that each input is only available to a single output.  Our RF Matrix Guide steps through the advantages for each matrix switch type.50MS-211    4 x 8 Blocking    DC    6 GHz    1 Watt    Electro-mechanical    Reflective    SMA
50MS-291    12 x 8 Blocking    700 MHz    3 GHz    0.1 Watt    Solid-state    Absorptive    N
50MS-305    18 x 4 Blocking    DC    6 GHz    1 Watt    Electro-mechanical    Absorptive    SMA
50MS-323    12 x 12 Blocking    700 MHz    3 GHz    1 Watt    Solid-state    Absorptive    N
50MS-334    2 x 12 Blocking    700 MHz    3 GHz    1 Watt    Solid-state    Absorptive    N
50MS-337    24 x 4 Blocking    700 MHz    3 GHz    0.1 Watt    Solid-state    Absorptive    N, SMA, TNC
50MS-342    2 x 18 Blocking    700 MHz    3 GHz    1 Watt    Solid-state    Absorptive    N
50MS-345    4 x 8 Blocking    DC    18 GHz    50 Watt    Electro-mechanical    Absorptive    SMA
50MS-356    2 x 12 Blocking    DC    26.5 GHz    0.25 Watt    Electro-mechanical    Absorptive    SMA
50MS-367    4 x 4 Blocking    DC    40 GHz    8 Watt    Electro-mechanical    Absorptive    2.92mm
50MS-380    4 x 4 Blocking    DC    18 GHz    50 Watt    Electro-mechanical    Absorptive    SMA
50MS-382    6 x 6 Blocking    DC    18 GHz    50 Watt    Electro-mechanical    Absorptive    N, SMA
50MS-403    8 x 8 Blocking    20 MHz    3 GHz    0.1 Watt    Solid-state    Absorptive    N, SMA
50MS-404    8 x 8 Blocking    DC    18 GHz    30 Watt    Electro-mechanical    Absorptive    N, SMA
50MS-421    8 x 8 Blocking    20 MHz    1 GHz    0.1 Watt    Solid-state    Absorptive    BNC, N, SMA
50MS-455    4 x 4 Blocking    DC    26.5 GHz    50 Watt    Electro-mechanical    Absorptive    3.5mm
50MS-466    2 x 6 Blocking    DC    18 GHz    50 Watt    Electro-mechanical    Absorptive    N, SMA
50MS-467    4 x 6 Blocking    DC    18 GHz    50 Watt    Electro-mechanical    Absorptive    N, SMA
50MS-470    4 x 4 Blocking    400 MHz    7.125 GHz    0.4 Watt    Solid-state    Absorptive    N, SMA
50MS-471    6 x 6 Blocking    400 MHz    7.125 GHz    0.4 Watt    Solid-state    Absorptive    N, SMA
75 Ohm Models
75MS-029    2 x 8 Blocking    3 MHz    1000 MHz    +13 dBm    Solid-state    IN Reflective, OUT Absorptive    F, N
75MS-030    2 x 6 Blocking    3 MHz    1000 MHz    +13 dBm    Solid-state    IN Reflective, OUT Absorptive    F, N
75MS-037    2 x 12 Blocking    DC    1700 MHz    +27 dBm    Electro-mechanical    Absorptive    F, N
75MS-053    8 x 8 Blocking    DC    1218 MHz    +20 dBm    Electro-mechanical    Absorptive    F
Maximum Active RF Path Examples
