Full Fan-out Transceiver Test Systems for Radio Testing
A full fan-out transceiver test system is constructed as a fully meshed matrix. There is a path between every pair of ports. Every path has its own individually controlled programmable attenuator. This construction is ideal for testing radio-to-radio communication because every path can be set to a unique dB setting.  The main cost driver for this design is the number of individually controlled attenuators.  The number of attenuators increase as the number of ports increase.

6 Port Design: 6 fully meshed ports with 15 paths and 15 attenuators
8 Port Design:  8 fully meshed ports with 28 paths and 28 attenuators
12 Port Design: 12 fully meshed ports with 66 paths and 66 attenuators
16 Port Design: 16 fully meshed ports with 120 paths and 120 attenuators
32 Port Design: 32 fully meshed ports with 496 paths and 496 attenuators

Each path through the matrix has its own individually controlled programmable attenuator. The programmable attenuators allow the transmission from one port to be received at all other ports at different signal levels. This allows the simulation of a network where each device has a different distance (i.e. attenuation setting) from all other devices. The attenuators can be remotely controlled to simulate static or dynamic environments.
50PMA-030    50 Ohm    8 Ports    127 dB    1 dB    200 MHz    2500 MHz    Keypad, Ethernet, RS-232    SMA
50PMA-036    50 Ohm    8 Ports    95 dB    1 dB    500 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-041    50 Ohm    32 Ports    63 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-044    50 Ohm    8 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-055    50 Ohm    16 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-069    50 Ohm    12 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-070    50 Ohm    16 Ports    95 dB    1 dB    2000 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-072    50 Ohm    4 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-074    50 Ohm    6 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-075    50 Ohm    6 Ports    95 dB    1 dB    2000 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-076    50 Ohm    8 Ports    95 dB    1 dB    2000 MHz    6000 MHz    Keypad, Ethernet, RS-232    SMA
50PMA-080    50 Ohm    6 Ports    95 dB    1 dB    500 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-081    50 Ohm    9 Ports    95 dB    1 dB    500 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-083    50 Ohm    4 Ports    95 dB    1 dB    500 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-092    50 Ohm    9 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-098    50 Ohm    5 Ports    95 dB    1 dB    2000 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-106    50 Ohm    4 Ports    95 dB    1 dB    2000 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-114    50 Ohm    5 Ports    95 dB    1 dB    30 MHz    3000 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-151    50 Ohm    8 Ports    63 dB    1 dB    2000 MHz    8000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-155    50 Ohm    12 Ports    95 dB    1 dB    350 MHz    6000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-161    50 Ohm    4 Ports    95 dB    1 dB    1 MHz    1000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-164    50 Ohm    6 Ports    95 dB    1 dB    1 MHz    1000 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-179    50 Ohm    4 Ports    95 dB    1 dB    2 MHz    30 MHz    Keypad, Ethernet, RS-232    N, SMA
50PMA-180    50 Ohm    6 Ports    95 dB    1 dB    2 MHz    30 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
50PMA-181    50 Ohm    8 Ports    95 dB    1 dB    2 MHz    30 MHz    Keypad, Ethernet, RS-232    N, SMA, TNC
