Alroc Tools LHS2 Tool
Brand: Alroc Tools
Model: LHS2
Description
Semiconductor Screen Stripping Tools
Alroc LHS2
The LHS2 cable tool, manufactured by Alroc, is used by MV-HV jointers to remove the semi-con screen when preparing a cable ready for the installation of joints, terminations or connectors. Alroc LHS2 enables the user to remove bonded semiconductor realising a right stop.
Back iron helps the user to tune the pitch of the tool making the rotation of the tool easy when removing the insulation. The LHS2 also works with silicone.
Alroc LHS2 – Technical Specification
| Cable Tool Part Number | Diameter | Tool Capacity | Dimensions | Packaging | ||
| Max cutting depth | Length | Width | Height | |||
| Alroc LHS2 | 38 – 60 mm 1,496 – 2,362 in | 5 mm / 0,197 in | 425 mm 16,732 in | 105 mm 4,134 in | 85 mm 3,346 in | None |
| Alroc LHS3 | 60 – 80 mm 2,362 – 3,150 in | 10 mm / 0,394 in | 460 mm 18,110 in | 130 mm 5,118 in | 85 mm 3,346 in | None |
| Alroc LHS4 | 80 – 110 mm 3,150 – 4,331 in | 12 mm / 0,473 in | 640 mm 25,197 in | 155 mm 6,102 in | 95 mm 3,740 in | None |
| Alroc LHS5 | 100 – 140 mm 3,937 – 5,512 in | 8 mm / 0,315 in | 730 mm 28,740 in | 195 mm 7,677 in | 115 mm 4,528 in | None |
