Metal sheath Tek-Rod® heating elements are available from stock. Three standard lengths in 120V and three lengths in 240V having 13 watts/in2 watt density are ideal for industrial and laboratory applications. The Tek-Rod® (epoxy) seal is moisture proof to 325°F to keep the element dry. The Incoloy 825 sheath provides resistance to corrosion, strength and the ultimate temperature sustainability.

Element construction begins with twin elements, compacted in Magne-sium Oxide (MGO) Leads and Transition on one end Unlike other "rod" type elements, HTS/Amptek® Tek-Rod® tubular heaters are small diameter, with the lead wire transition on one end of the assembly for easy hook-up. Soft annealed for easy bending Tek-Rod® can be easily configured to valves tubes and vessels. The minimum bend radius 1/2 (12mm). Smooth tip (no enlarged diameter end cap) The end termination is isolated and welded closed in a smooth, non-intrusive radius. Moisture Proof Tek-Rod® structures are entirely enclosed and dry, with the single opening epoxy sealed to keep moisture out. The two conductor resistance wires are designed for ohm stability and durable flexibility...10 1000°F, with exposure to 1,382F (750°C). 4ft, 6ft, and 8ft 120v, 12ft and 16ft 240v. HTS/Amptek® Tek-Rod® are proudly manufactured in North America and assembled in Texas.

Heating jackets and insulator jackets work to maintain the temperature of an object or fluid by trapping heat inside. The insulation prevents heat from escaping the system, and it can save energy or require less power to achieve and maintain an ideal temperature.

Heating jackets use a heating element to maintain the correct temperature. This configuration can use a multi-stranded tape-type heating element or a self-regulating cable-type element to achieve the desired temperatures to ensure that gases or fluids stay at the proper temperature. Insulator jackets, unlike heating jackets, do not use a heating element to control the temperature. Instead, the insulation itself works to maintain the temperature of whatever object or fluid the jacket surrounds.

Manufacturers, industrial plants and laboratories often need to keep a range of fluids and gases at consistent temperatures, such as water, asphalt, hydrocarbons and plastics. Heating jackets safely regulate temperatures inside plumbing or other duct work without affecting surrounding systems. Typical heating jackets and insulator jackets are available in cylindrical or flat shapes, and are perfect for heating or insulating round pipes or large, flat expanses.

Many industries and laboratories often require specially shaped pieces of plumbing, equipment and machinery that must maintain a certain temperature, as well. Our team can design a custom-built sleeve that can cover the object, fitting around irregularly sized and shaped elements and allowing the regulation of internal temperatures. Sleeved jackets for uneven surfaces are available as a thermal heating sleeve or as an insulator jacket only.

AWH-052-020D

AWH-052-020D

AWH-052-040D

AWH-052-060D

AWH-052-080D

AWH-052-100D

AWH-052-120D

AWH-052-160D

AWH-102-020D

AWH-102-040D

AWH-102-060D

AWH-102-080D

AWH-052-020DM

AWH-052-040DM

AWH-052-060DM

AWH-052-080DM

AWH-052-100DM

AWH-052-120DM

AWH-052-160DM

AWH-102-020DM

AWH-102-040DM

AWH-102-060DM

AWH-102-080DM

AWH-102-100DM

AWH-052-020DL

AWH-052-040DL

AWH-052-060DL

AWH-052-080DL

AWH-052-100DL

AWH-052-120DL

AWH-052-160DL

AWH-102-020DL

AWH-102-040DL

AWH-102-060DL

AWH-102-080DL

AWH-102-100DL

AWH-102-120DL

AWH-102-160DL
