Through Bore (TB)
The TB 1.0 model is available with 6, 12, and 20 conductors, designed to fit shafts ranging from .375 to 1.00 inches in diameter. Our units feature durable NEMA 4X enclosures, making them ideal for operation in corrosive environments. If your application requires a nonstandard bore size, we can create custom mounting sleeves to accommodate sizes from .375 to 1.00 inches.

Additionally, our TB models can be modified for wire sizes up to 16 AWG, leads tailored to customer specifications, with the option to integrate CAT5.

Standard Specification
Operating Current
Operating Voltage
Electrical Noise
Leakage Resistance
Temperature Range
Enclosure
Leads
7.5A (options up to 32A)
1,000 Vrms
5μV, P–P, BW = 10Hz–10kHz at 8.5 mA, 500rpm
10,000 MΩ (min)
-30°F to 175°F
Stainless Steel
​20 AWG TFE covered wire, 3 ft long
Options
​Bandwidth
​Wire
Wire Leads
Mounting
​DC to 250 MHz
​Coax, twisted pair, thermocouple, or customer specified wire/cable
3 ft standard length or to customer specs
.375"-1.0" Bore Diameter
​
Sample Applications Include:
Oceanographic Instrumentation
Food Processing
Packaging Machines
Bottle/Can Fillers
Measurement and Sorting Equipment
Defense Applications
Signal Transfer
Stress and Torque Reading
Temperature Control
