Dew/frost point calibration ranges:
50 to -112°F (10 to -80°C) with data from 68 to -166°F (20 to -110°C)
-4 to 140°F (-20 to 60°C) operating temperature
Accuracy:
±3.6°F (±2°C) above -148°F (-100°C)
±5.4°F (±3°C) below -148°F (-100°C)
Repeatability:
±0.4°F (±0.2°C) above -148°F (-100°C)
±0.9°F (±0.5°C) below -148°F (-100°C)
Thin-film aluminum oxide moisture sensor
NTC thermistor temperature sensor type
±0.9°F (±0.5°C) overall accuracy
Solid state/piezoresistive pressure sensor type
±1% of full scale accuracy
Pressure ranges up to 5000psig (345bar)
12 to 28VDC power supply
4-20mA analog and HART digital output
