Create Custom Waveforms and Sequences
The N4A AC Source also features 10-bit vertical resolution and a maximum waveform resolution of 16,384 points to produce a single periodic waveform. There is also an internal storage function for imported custom wave forms featuring user intuitive library menus that display the waveform graphically on the user interface.

The N4A range of AC+DC Power Sources are available with a variety of output power ratings from 6kVA up to and above 30kVA. They are the perfect solution for general power source applications as well as IEC61000 electromagnetic compatibility standards testing, offering low THD and excellent reliability.

N4A AC+DC Power Sources – High Power, Low Distortion, 1kHz full signal bandwidth
Model
Output Power
Bandwidth
Output THD %
Output Phases
Maximum Output Current (Continuous)
Maximum Output Current (3 second inrush)
N4A03    3kVA
1kHz Full Signal,

15kHz Small Signal

<0.3%    1 Phase    10Arms    20Arms
N4A06    6kVA    20Arms    40Arms
N4A18    18kVA    3 Phase (Optional 1 phase output)    20Arms/phase    40Arms/phase
N4A30    30kVA    3 Phase (Optional 1 phase output)    32Arms/phase    64Arms/phase
N4A67    67kVA    3 Phase    75Arms/phase    100Arms/phase
