High performance at economical process is available from the Fairchild T7800 series of piezo-ceramic actuated I/P transducer. These units offer state of the art accuracy up to 0.15% FS. The disc actuation mechanism provides a product that is totally impervious to shock, vibration and positional orientation. In the Extended Range units, an additional Relay Section amplifies the output pressure to obtain up to 0-120 psi [0-8.0 BAR], (0-800 kPa) output. The T7800 series is approved for Intrinsic Safety and Non-Incentive use carries FM, CSA, ATEX and IECEx approvals.

Electrical Connection - 1/2"NPT Conduit

Input - 0-10 VDC

Output - 0-120 psig
