API 4300 G
Specify input range
Factory configured
0-100 mVDC to 0-500 VDC
±100 mVDC to ±10 VDC
0-100 μADC to 0-900 mADC

Specify output range
Factory configured
0-1 V to 0-10 V
±1 V to ±10 V
0-1 mA to 0-20 mA, 4-20 mA

Hot-swappable plug-in design
Replaces Action AP 4300
I/O LoopTracker LEDs
Output test button
Full I/O/power isolation
18 V loop power supply
Uses API-008 8-pin socket
115 VAC powered
A230 option for 230 VAC
P option: 85-265 VAC, 60-300 VDC power (+$60)
D option: 9-30 VDC power (+$60)

API 4310 G Narrow/Low Input
Specify input range
Factory configured
0-10 mV to 0-100 mV
±10 mV to ±100 mV
0-100 μA to 0-1 mA

Specify output range
Factory configured
0-1 V to 0-10 V
±1 V to ±10 V
0-1 mA to 0-20 mA, 4-20 mA
I/O reversal available
Hot-swappable plug-in design
Replaces Action AP 4310
I/O LoopTracker LEDs
Output test button
Full I/O/power isolation
18 V loop power supply
Uses API-008 8-pin socket
115 VAC powered
A230 option for 230 VAC
P option: 85-265 VAC, 60-300 VDC power (+$60)
D option: 9-30 VDC power (+$60)
