Hermetically Sealed Stainless Steel Shear Beam Load Cell
 FEATURES
 Rated capacities of 1000 to 10,000 pounds
500 kg to 5 metric tonnes
 Stainless steel, welded seal construction
 Interchangeable with Sensortronics model 65023 shear
beam
 Trade certiied for NTEP Class III: 5000 Divisions and
Class IIIL: 10000 Divisions; OIML R60: 3000 Divisions
Hermetically Sensorgage™ sealed to IP68 standards
 Cell Guard™ two year warranty
Factory Mutual System Approved for Classes I, II, III;
Divisions 1 and 2; Groups A through G.
Also, non-incendive ratings (No barriers!)
Optional- Companion weigh module is Model 65080 Stainless
Steel TantaMount
 APPLICATIONS
 Hostile environments: Food and beverage processing
Chemical and plastics processing
Pharmaceutical and biomedical processing
Washdown and Clean-In-Place environments
High performance weighing modules and assemblies
DESCRIPTION
The Model 65083H provides the weighing industry with
the ultimate protection necessary for today’s hostile
environments in an economical, low proile range suitable
for platform scale manufacture.
 OUTLINE DIMENSIONS in inches [millimeters]
 65080-TWA
 Its low proile and fully welded sealing combined with
high accuracy makes this load cell ideally suited for low
proile platforms, pallet truck weighers, tanks and silos.
The guide slots incorporated into the upper and lower
mounting faces enable manufacturers to easily position
the load cell.
 Hermetically sealed against moisture, the construction of
the model 65083H, in combination with a polyurethane
dual shielded cable, enables continuous operation
in demanding environments while maintaining a high
operating speciication.
 The two additional sense wires feed back the voltage
reaching the load cell. Complete compensation of
changes in lead resistance, due to temperature change
and/or cable extension, is achieved by feeding this
voltage into the appropriate electronics.3510-300KG；3510-500KG；3510-750KG；3510-1000KG；3510-1200KG；3510-2000KG；3510-3000KG；3510-5000KG；3510-1000lbs；3510-1500lbs；3510-2500lbs；3510-4000lbs；3510-5000lbs，355-5kg、355-10kg、355-20kg、355-30kg、355-50kg、355-100kg、355-200kg、355-250kg、355-500kg，1410-5kg、1410-10kg、1410-20kg、1410-30kg。1410-10kg、1410-20kg、1410-30kg，1010-3kg、1010-5kg、1010-7kg、1010-10kg、1010-15kg、1010-20kg、1010-30kg、1010-50kg、1010-90kg，20-10000kg、120-20000kg、120-30000kg、120-50000kg，1140-15kg、1140-20kg、1140-30kg、1140-50kg、1140-75kg、1140-100kg、1140-150kg，1015-3kg1015-5kg 1015-7kg 1015-10kg1015-15kg 1015-20kg 1015-30kg 1015-50kg 1015-90kg，1320-1000kg、1320-1500kg、1320-2000kg。1320-1000kg，1330-500kg、1330-750kg、1330-1000kg。1330-500kg、1330-750kg，3310-250kg、3310-500kg、3310-750kg、3310-1000kg。3310-250kg、3310-500kg
