PRODUCT DETAILS
Miniaturized Multi-Component Borehole Sonde String

The DW-150 is a miniaturized, multi-component borehole sonde string utilizing an ultra low-noise digitizer, which enables the recording of low-amplitude microseismic events, 3D-VSP, and crosswell seismic imaging.

Features
24-bit x three-channel digitizer in each shuttle
Ultra low-noise digitizer enables recording of low-amplitude microseismic events, 3D-VSP, Crosswell Seismic Imaging, etc
Slim-hole sonde 1.6 inch OD (<41 mm)
3C sensor packages available: 3C tri-axis orthogonal Geophone
OMNI-2400 high-output Geophone sensors
Machined stainless housing minimizes mechanical resonance for high-resolution, high-frequency recording
Direct connection sub-arrays, armored wireline, or rigid interconnects available with high-pressure multi-conductor booted connectors
Flexible or rigid interconnects may be connected “back-to-back” to form longer intervals
Maximum distance between sonde modules: 100 meters
Maximum temperature rating: 150°C
Maximum pressure rating: 20,000 psi
Configurations for vertical, deviated, or horizontal wellbore deployments
Adaptable housing for user-defined, application-specific coupling devicesMechanical Specifications
Outside Diameter
1.6 inches
< 40.64 mm
Length
16 inches
406.4 mm
Tool Weight
5 lbs.
2.27 kg
Anchoring System
Mechanical on each shuttle (bow spring/magnetic)
Tubing mandrel Permanent (cemented)
Anchor-to-Weight ratio
7:1 (passive spring)
Tool Anchoring Range
Custom adapters for dimension ranges
Sizes available upon request
Points of Contact
5 points, including oposing clamp axis
Sensor Package
3C w/OMNI-2400, mutually orthogonal sensor set standard 2.26
Volts/inch/second Sensitivity
Interconnect Options
Rigid Tubing
Flexible Armored Wireline Cable
Standard Lengths
3, 6, 9, 9, 12, 15, 20 meters
Maximum Temperature
302°F
150°C
Maximum Pressure
20,000 psi
