INDUSTRY LEADING TECHNOLOGY
 Clean & Innovative Design
 • Smooth frame design for ease of cleaning
 • Capable of multiple curves as well as inclines and declines
on a single conveyor
 • Plain bend corners with 24" on centerline radius use FDA approved
oil impregnated wear strips
 • Inclines and declines available up to 30 degrees
 •
 Incline angles are integrated into the intermediate modules
 Innovative Transfer Options
 • Powered Transfers
 •
 •
 •
 Provides smooth in line transfer of small parts
 Slave driven off of drive or idler module
 Transfers parts as small as 3" in diameter
 • Standard Tails Side to Side Transfer
 •
 •
 Side by side drive / idler tail
 1" from chain edge to edge
 • Side Transfer Modules
 •
 •
 Intermediate module that brings chain past the frame edge
 1/8" from chain edge to edge
 Compact Drive Module & Idler Tail
 • Idler Tail
 •
 •
 •
 •
 12" long
 Bearings are located inboard
 Flush design for side transfers
 Sprocket comes standard for added shaft or
       powered transfer
 • Drive Tail
 •
 •
 24" long with a 5" diameter sprocket
 Catenary belt take-up with sight gauge
 Drive Tail
 •
 Motor can be mounted to the side or underneath
 Idler Tail
 The Benefits of a Dorner AquaGard 7100 Series Conveyor
 Industry Ready
 • 300 Series Stainless Steel frame
 • All materials are FDA approved plastics and Stainless Steel
 Quality Construction
 •  FDA approved oil impregnated wear strips on curves
 • Bolt together construction for modularity and future add-ons
 Time Saving
 • Dorner’s online configurator engineers simple or complex conveyors to meet your needs in minutes
 • The industry leading tool delivers a complete 3D CAD assembly model for instant validation of fit
 • 7100 Series conveyors are shipped in sub-assemblies for fast and simple installation
