Pulse-Echo (P-E) measurement range: 0.025 to 36in (0.63 to 914.4mm)
• Measurement resolution: 0.001in (0.01mm)
• 120MHz FPGA timing
• 150 volt square wave pulser
• Adjustable gain (40-52dB) in 3dB steps
• Velocity range: 0.0120 - 0.7300in/μs (305 - 18,542m/s)
• Pulse repetition frequency: 200Hz
• Display update rate: 10Hz
• High speed scan speed at 100Hz
• Dual element transducer (1 to 10MHz)
• Automatic V-path / dual path error correction
• Multi-function, 7-segment, 4.5-digit liquid crystal display
• 32 megabit flash memory
• USB download cable
• Factory calibration traceable to NIST & MIL-STD-45662A
• 5-year limited warrantyThe Dakota NDT ZX5-DL thickness gauge and data logger is a basic dual element thickness gauge with the ability to locate blind surface pitting and internal defects and flaws in materials. The ZX5-DL is capable of measuring the thickness of various materials with accuracy as high as ±0.001 inches (±0.01 millimeters).
The High Speed Scan feature of the ZX5-DL increases the overall repetition rate to a maximum of 140Hz with a high speed screen refresh rate of 25 times a second. This allows for making scanned passes over an arbitrary length of the test material, while still maintaining a reasonable representation of thickness over the area or region scanned.
The ZX5-DL has an on-board data logger that stores 10,000 readings in 40 files of 250 readings per file.
Dakota NDT ZX5-DL Thickness Gauge and Data Logger Applications
• Corrosion and pitting
• Tube and pipe
• Tanks
• Boilers
• Glass
