100MHz DSP platform with FPGA technology
• Measurement modes:
◦ Pulse-Echo (P-E): contact transducers
◦ Echo-Echo (E-E): contact transducers
◦ Echo-Echo Verify: (E-EV): contact transducers
◦ Interface-Echo (I-E): delay line and pencil transducers
◦ Interface-Echo-Echo (I-E-E): delay line and pencil transducers
◦ Pulser: square wave pulser with adjustable pulse width (spike, thin, wide)
◦ Receiver: manual or AGC gain control with 110dB range
◦ Timing: precision TCXO timing with single shot 100MHz 8-bit ultra low power digitizer
• Display views: A-Scan, B-Scan, Large Digits, Scan Bar, Bar Graph
• A-Scan display: + Rectified, - Rectified, Full Waveform (RF)
• B-Scan display speed: 10 to 200 readings per second
• Resolution (selectable): +/- 0.001in (0.01mm) or +/- 0.0001in (0.001mm)
• 64 custom user-defined setups
• Visual and audible alarm with high and low limit settings for specific application tolerances
• High speed scan: 250 readings per second
• 110dB gain range
• 4Gb internal memory
• Data management software
• 1/8in VGA (grayscale) display
• Factory calibration traceable to NIST & MIL-STD-45662A
