Dakota NDT Thickness Gauge FX81-DL
PricePrice upon Request
BrandDakota NDT
ModelFX81-DL
Item No.
- Display views:
- Flaw Detector: Full wave, +/- Rectified, or RF
- Thickness Gauge: Digits, +/- Rectified, RF, or B-Scan
- Resolution: 0.001in (0.01mm), 0.0001in (0.001mm) selectable
- Timing: Precision TCXO timing with single shot, 100MHz, 8-bit ultra low power digitizer
- Thickness gauge measurement modes:
- Pulse-Echo (P-E): pit and flaw, 0.025 to 100ft (0.63mm to 3048cm)
- Pulse-Echo Coating (PECT): material, coating, pit, and flaw, 0.025 to 100ft (0.63mm to 3048cm)
- Pulse-Echo Temp Comp (PETP): pit and flaw, auto temperature compensation, 0.025 to 100ft (0.63mm to 3048cm)
- Echo-Echo (E-E): thru paint and coatings, 0.05 to 4in (1.27 to 102mm)
- Echo-Echo Verify (E-EV): thru paint and coatings, 0.05 to 1in (1.27 to 25.4mm)
- Coating Only (CT): coating thickness, 0.0005 to 0.1in (0.0127 to 2.54mm)
- Flaw detector measurement mode:
- Pulse-Echo (P-E): 0.025in to 100ft (0.63mm to 3048cm)
- Frequency Band:
- FX81-DL: Broadband 1.8 - 19MHz (-3dB); six narrow bands at 0.5MHz, 1MHz, 2MHz, 5MHz, 10MHz, 15MHz
- One- and two-point calibration option for material and coating, or selection of basic material types
- Auto probe zero, recognition, and temperature compensation
- Up to 50 readings per second in high speed scan mode
- 64 user-definable setups transferrable to and from a PC archive
- 4Gb internal memory
- Direct USB 1.1 PC connectivity
- Blanview sunlight readable QVGA TFT color display
- Factory calibration traceable to NIST & MIL-STD-45662A
- 2-year limited warranty
