Badger's Industrial Turbine is a rugged, reliable meter ideally suited for chemical or industrial fluid applications. Its compact size and ease of serviceability without removal from the line, coupled with a choice of materials, make this a cost effective selection. Designed with performance in mind, the meter provides a high level of accuracy over a wide flow range with a minimum of pressure loss.

The Badger Meter Turbine is available in line sizes of 2", 3", 4" and 6" with a choice of flange ratings and three different body materials including stainless steel. Its unique straight through flow profile and ceramic bearing design optimize performance.

To complement the meter, Badger offers a complete line of accessories that includes mechanical, pneumatic, electromechanical and state-of-the-art electronic transmitters, totalizers, indicators and process controllers.

The Badger Meter Industrial Turbine is a volumetric liquid flow meter which works on the time proven principle of a rotor turning at an angular velocity proportional to the fluid velocity through the turbine. The meter has straightening vanes and a nose cone in the inlet side which minimize upstream turbulence and direct the flow to the rotor effectively. Electronic pickups generate signals from the rotor magnet. This is translated to 4-20 mA and/or open collector-transistor pulse outputs. Mechanical pickups and electromechanical outputs are also available.
