schwarzbeck NNLK 8129 Stabilisation Network

NNLK 8129 - Line Impedance Stabilisation Network

Topology:
V-LISN

Frequency Range:
(9 kHz) 150 kHz - 30 MHz

Impedance simulation:
50 µH || 50 Ω

Max. Voltage:
250 VAC 50/60 Hz
400 VDC

Max. Current:
4 x 200 (300) A

Mains terminals:
4 wing terminals

Terminals for E.u.T.:
4 wing terminals

Length:
604 mm

Width:
446 mm

Height:
355 mm

Weight:
30.5 kg

Standard:
CISPR 16-1-2

Datasheet NNLK 8129

Data

Optionen:
Opt. RC
Option RC for LISN: Remote Control with built in power supply. LISN can be controlled by R&S or Schwarzbeck code, including remote control cable for your receiver type (Please specify your receiver type!). LISN can be selected from the R&S receiver menu or in the EMC32 software like an R&S LISN. No programming of the user interface necessary. Functions: path selection and PE grounded or via choke.

NNLK 8129 Opt. RC

Opt.400/700 V:
400/700 V Voltage to ground / Voltage between lines

Opt.Lüfter:
Cooling Fans

Opt. TC
The temperature monitor modul which is optional available for the NNLK LISN warns the user optical and acoustical when the temperature gets too high. It controls the fans of the LISN temperature-dependent, too and thus prevents overheating. If a critical temperature is reached the temperature control modul indicates this optically and acoustically.

NNLK 8129 Opt. TC
